SAVER AM เครื่องบันทึกข้อมูลการขนส่งสินค้า

SAVER AM Asset Management

Product Features

§  Full waveform data recorder

§  User-programmable trigger threshold

§  User-defined pre-trigger recording (so you know what happened before the event took place)

§  LED alarm indicator for shock, Temp/RH, Remaining Battery Life, Atmospheric Pressure, Tilt

§  Push button, delayed start or instantaneous activation

§  USB connectivity for communication and instrument power

Product Specifications

• Envelope Size: 2.8 x 2.6 x 1.3 in. (71 x 66 x 33 mm)
• Acceleration Range: 200g (full scale)
• Accelerometer Type: Triaxial piezoelectric
• Sampling Rates: 500, 1000, 2500 and 3000 samples per second
• A/D Conversion: 12-bit
• Anti-Alias Filter: 5-pole, low pass filter 50, 100, 250 and 300 Hz
• 3-dB Frequency Response: 0.5 Hz to filter setting
• Temperature Measurement Range:  -20° to 60°C (-4° to 140°F)
• Humidity Measurement Range: 5% to 95% RH, non-condensing
• Atmospheric Pressure Measurement Range: 10 to 1100 mbar
• Light Sensor Measurement: 0 to 2000 Lux
• Tilt Detection: +/- 45 degrees from orientation
• Light Detection: On / Off
• Memory Retention Modes:
• Signal – Top 400 Events (Max Overwrite)
• Timer – Fill Stop – up to 10,000 events (static measurements)
• Certifications:
• CE
• IP 67
